GIS Data Collector U12
Short Description:
The U12 mobile GPS data collector adopts Microsoft’s Windows Mobile 6.X operating system, integrating professional Compass/GPS module, HD camera, GSM/3G, HD touch screen, Bluetooth and WiFi, to achieve real-time data acquisition and processing without time/space restriction. The U12 features compact and light, ergonomic design, easy to use and carry, IP54 protection, 1.2 meter drop protection, rugged. Specification System lWindows Mobile 6.x lChinese/English/French/Japanese/Russian...
The U12 mobile GPS data collector adopts Microsoft’s Windows Mobile 6.X operating system, integrating professional Compass/GPS module, HD camera, GSM/3G, HD touch screen, Bluetooth and WiFi, to achieve real-time data acquisition and processing without time/space restriction.
The U12 features compact and light, ergonomic design, easy to use and carry, IP54 protection, 1.2 meter drop protection, rugged.
Specification
|
System lWindows Mobile 6.x lChinese/English/French/Japanese/Russian etc lHigh speed 800MHz, 32-bit ARM processor, 256M DDR RAM, 1GB storage lLatest variable frequency and voltage regulation technology, low power consumption l5MP HD camera, speaker and microphone, convenient data collection in field at any time lReplaceable 3000 mAh Li-Ion batteries, long working hours GPS l167-channel, GPS/BDS system support lOZSS/WAAS/MSAS/EGONASS/GAGAN support lAccuracy: Position: 2.5 m CEP SBAS: 2.0 m CEP RTCM IN: 1.5 m CEP Reacquisition time: <2 s lNMEA, binary protocol Standard Accessories lReplaceable Li-Ion batteries, 3.7V, 3000 mAh lStrap and touch pen |
lUSB data cable lAC charger (Input: 110-240V, Output: 5V-1000mA) lCD lManual lOperation Guide Optional Accessories lBag lExternal PATCH antenna lCradle charger lExternal serial line Communication lBluetooth V2.0, WiFi lGSM/3G (WCDMA, CDMA) lUSB 2.0 lRS232 Physical lDimension: 158 mm x 85 mm x 25 mm lWeight: 280 g lInterface: USB, serial port, SIM card, TF card, external antenna, MCX interface Environment lOperating Temperature: -20 ~ +60℃ lStorage Temperature: -30 ~ +70℃ lIP Protection: IP54, 1.2 meter drop protection |
